أوتوماتيكي بالكامل Toilet Paper Making Machine Angola

1.نظرة عامة على المنتج من Complete Converting Line for Small‑Roll Toilet Tissue Production

إن ماكينة صنع ورق التواليت is a complete converting production line that processes jumbo parent tissue paper rolls (raw materials: virgin wood pulp, recycled pulp or bamboo pulp) into consumer‑ready small toilet paper rolls. The full automatic toilet paper making machine Angola configuration consists of three core units: toilet paper rewinder, automatic band saw cutting machine and automatic multi‑roll packaging machine.

Supplied by ماكينة NRC (Qingdao New Richuan Precision Machine Co.,Ltd.), this integrated line targets Angola and other African market tissue manufacturers, supporting production of cored toilet rolls, core‑less toilet rolls, pressed flat rolls and kitchen towel products. The whole line runs under unified PLC control to lower labor input and deliver stable finished‑product quality.

2.Core Composition of Full‑Automatic Toilet Paper Production Line

2.1  ماكينة ترجيع ورق التواليت

This is the host unit of the toilet paper making machine. It handles jumbo‑roll unwinding, perforation, embossing, rewinding, tail gluing and log ejection. Multiple optional embossing modes and adjustable perforation pitch satisfy diversified tissue product requirements.

Main Technical Description for Rewinder:

• Supports raw‑paper width up to 3500 mm for bathroom tissue, kitchen towels and industrial large‑diameter rolls up to 300 mm. Variable perforation length for different roll‑sheet lengths. Maximum running speed reaches 260 m/min at 6 cycles per minute, equipped with dual embosser sets (steel‑to‑rubber or steel‑to‑wool roller).
• Two or three unwinding backstands with dual‑belt or triple‑belt jumbo‑roll feeding system; pneumatic jumbo‑roll loading; max jumbo roll diameter 1500 mm.
• Automatic log change‑over, log ejection, edge trimming, tail gluing and sealing. Reserves ~20 mm paper tail for easy consumer tear‑off without paper damage.
• Timing‑belt, nylon‑belt and gear transmission for stable running and convenient maintenance. Multiple photoelectric sensors detect paper‑out, core‑missing and abnormal conditions for auto‑stop. Key parts are equipped with lubrication system.
• Main motor power:7.5‑35 kW with variable‑frequency control, final power depends on custom specifications.
• Full‑line PLC control; PLC brand selectable by customer.

2.2  آلة القطع بالمنشار الشريطي الأوتوماتيكي

After rewinding, continuous paper logs are delivered to the band‑saw cutter, which cuts logs into individual toilet‑roll blanks with high‑length accuracy.

Main Technical Description for Band‑saw Cutter:

1. Simple‑operation structure, low noise, stable running and high output efficiency.
2. PLC program control, variable‑frequency speed regulation, touch‑screen human‑machine interface.
3. Servo‑motor driven feeding system ensures precise cutting dimension.
4. Double‑side timing‑belt paper feeding; advanced photoelectric detection system.
5. Cutting speed and target length can be set directly on touch‑screen; smooth pushing‑cutting performance.
6. Optional automatic sharpening feed system; oblique‑cut correction via manual‑auto combined adjustment.

2.3  Automatic Multi‑Roll Packaging Machine

The last station of the toilet paper making machine line. It bundles cut toilet‑roll blanks into finished multi‑roll packs for warehouse and supermarket sales.

3.Full‑Line Production Workflow

1. Load jumbo parent tissue rolls on unwinding stands;
2. Unwinding → tension adjustment → perforation → embossing → rewinding to form continuous paper logs;
3. Automatic log ejection and conveyor transfer to band‑saw cutter;
4. Fixed‑length cutting into single toilet‑roll blanks;
5. Transport blanks to multi‑roll packaging machine for grouping and sealing;
6. Output final packaged toilet‑paper products.

4.Machine Advantages for Angola Market

1. أتمتة عالية المستوى: Reduces workshop labor demand, suitable for medium‑to‑large‑scale tissue factories in Angola.
2. Raw‑material compatibility: Accepts virgin wood pulp, recycled pulp and bamboo‑pulp jumbo rolls, matching local raw‑material supply conditions.
3. Rich‑product flexibility: Manufactures cored rolls, core‑less rolls, flat‑pressed toilet rolls and kitchen towel rolls. Multiple embossing and perforation options support differentiated brand positioning.
4. Robust industrial‑grade build: Designed for long‑hour continuous operation; easy‑access maintenance structure.
5. Customizable configuration: Machine width, PLC brand, sharpening device and unwinding quantity can be adjusted according to user budget and production objectives.
6. Complete after‑sales support: Technical documentation, operation video, remote guidance and overseas technical‑service options are available.

5.الأسئلة الشائعة

Q1: What raw‑paper materials can this toilet paper making machine process?

A: It works with jumbo parent tissue rolls made from virgin wood pulp, recycled pulp or bamboo pulp. Paper grammage should match standard tissue‑paper specifications for toilet‑tissue production.

Q2: What is the required workshop condition for running the full‑automatic line in Angola?

A: Power supply: 3‑phase 380V/50Hz; independent air compressor providing air pressure of 0.5‑0.8 MPa (customer‑supplied). Sufficient floor space is required for placing rewinder, band‑saw cutter, packaging machine and connecting conveyors.

Q3: Can I adjust finished‑roll size and perforation spacing?

A: Yes. Roll length, perforation pitch, embossing pattern and finished‑roll diameter can be set via touch‑screen and mechanical adjustment without major hardware modification. Special core‑tube inner diameters can be custom‑ordered.

Q4: What after‑sales services does NRC MACHINE provide?

A: Standard machine warranty is provided. We supply complete user manuals, operation‑training videos, remote online troubleshooting. Spare‑parts can be supplied at cost after warranty expires; overseas engineer‑dispatch service is optional upon client request.

Q5: What information should I prepare for an accurate quotation?

A: Please inform us of: target maximum raw‑paper width, types of finished products (cored / core‑less / kitchen towel), expected daily output, preferred PLC brand, local power condition, and any special customization requirements.

Q6: How long is the production lead‑time after order confirmation?

A: Production cycle depends on model and custom items. Our sales team will give you exact lead‑time once your technical requirements are confirmed.
